Overhauling the Roborock S5 for Inconsistent Suction Power

Introduction

The Roborock S5 is a popular robot vacuum that combines efficient cleaning with smart navigation. Many users report a drop in suction power after a few months of regular use, leading to streaks of dust on hardwood floors and stubborn debris left behind on carpets. The good news is that inconsistent suction is rarely a sign of a broken unit. Most of the time, it can be traced to a build‑up of dirt in a few key components. In this guide we will walk through a comprehensive overhaul of the S5, giving you a step‑by‑step plan to restore its original cleaning performance.

We’ll cover everything from a basic dustbin check to a deeper inspection of the fan assembly. Whether you’re a first‑time owner or a seasoned robot‑vacuum enthusiast, these steps will help you keep your S5 running like new. If you’re unfamiliar with robot vacuum maintenance, you’ll find the instructions easy to follow, and we’ll point out where to find replacement parts if needed.

Understanding Suction Mechanics

Before diving into the disassembly, it helps to know how suction works in a robot vacuum. The S5 employs a two‑stage vacuum system: the brushroll agitates the carpet, and a powerful motor draws air through a series of filters into a cyclone chamber. The cyclone separates dust from the airflow; the dust falls into a collection bin while clean air returns to the vacuum’s interior.

Suction power is influenced by a few critical variables:

1. Fan speed – the motor’s RPM, set by the device’s firmware.
2. Airflow path – a clear route from the intake to the cyclone.
3. Filter efficiency – how much airflow the filter lets through.
4. Brushroll condition – how effectively it lifts dirt from the surface.

When any part of this chain becomes clogged or worn, suction drops. Recognizing where the blockage is will guide the repair process.

Common Causes of Low Suction

Even with regular use, certain factors can diminish suction:

• Dust‑laden filters: The S5 uses a reusable HEPA filter that traps a large amount of fine dust. If not cleaned, it becomes a choking point.
• Blocked vacuum port: Small debris or hair can get lodged in the air inlet.
• Worn brushroll: Tangled fibers or missing bristles reduce the brush’s ability to disturb surface dirt.
• Clogged fan: Hair or small objects can wrap around the fan blades.
• Loose screws or connections: Vibration over time can loosen internal components, creating gaps in the airflow path.
• Battery drain: A partially drained battery can reduce motor output, especially on the higher power modes.

Identifying which of these is at play is essential before spending time on a full overhaul. A quick visual inspection can often reveal the culprit.

Tools and Preparation

Gathering the right tools will make the process smoother and reduce the risk of damaging the robot.

Place the Roborock S5 on a flat, clean surface. Turn it off completely and unplug it from the charging dock. It is safer to work on a dry area to avoid electrical mishaps.

Step 1: Inspect and Clean the Dustbin

The dustbin is the first line of defense against a drop in suction. A full bin can block airflow from the intake.

1. Remove the dustbin by lifting the tab on the bottom of the robot.
2. Empty the contents into a trash bin.
3. Check the bin for residual dirt that might be trapped under the rim.
4. Wipe the inside with a damp cloth; be sure to dry it completely before reassembling.

If you notice that the bin is almost full after a short period, the filters may be the issue.

Step 2: Check the Brush and Brushroll

The brushroll is vital for lifting dirt from the floor into the suction path.

• Detach the brushroll: Depending on your S5 model, you may need to loosen a latch or unscrew a small screw.
• Inspect the bristles: Look for hair tangles, frayed bristles, or missing sections.
• Clean the bristles: Use a small brush or your fingers to tease out tangles.
• Rotate the brushroll manually: Ensure it turns freely. If it resists, it may need a new replacement.

Tip: The S5 comes with a brushroll that can be swapped out easily. If your brushroll shows significant wear, consider purchasing a replacement from the manufacturer.

Step 3: Clean or Replace Filters

Filters are often the biggest culprit in suction loss. The S5’s HEPA filter can hold a surprising amount of dust.

1. Locate the filter inside the robot, usually near the intake.
2. Remove the filter carefully.
3. Inspect for visible dust: A thick layer of dust indicates it’s time to clean or replace.
4. Clean the filter: Rinse gently under lukewarm water, let it dry completely (this may take a few hours). Avoid harsh chemicals that can damage the filter’s fibrous structure.
5. Check for damage: If the filter is torn, warped, or heavily clogged, replace it with a new one.

Note: Replacing the filter can improve suction by 20–30% in many cases.

Step 4: Examine the Vacuum Port and Air Filter

The vacuum port is where air enters the robot. If it’s blocked, the entire suction system struggles.

• Open the intake vent: A small flathead screwdriver or a plastic pry tool works.
• Use tweezers to pull out any hair or debris.
• Wipe the area with a dry cloth.

After clearing the port, examine the air filter that sits directly behind it. A clogged air filter can restrict airflow.

• Remove the filter and inspect it.
• Clean it with a vacuum cleaner or a damp cloth.
• Replace if it’s visibly dirty or damaged.

Step 5: Inspect the Suction Fan

The fan is the heart of the suction system. A wrapped or damaged fan dramatically reduces airflow.

1. Remove the top cover of the S5 by unscrewing the screws on the back and gently lifting the panel.
2. Locate the fan: It’s a small, circular unit driven by the motor.
3. Check for obstructions: Hair, dust, or small objects can cling to the blades. Use tweezers to remove them carefully.
4. Spin the fan manually to see if it turns freely.
5. Listen for unusual noises: A squeaky or humming fan may need lubrication or replacement.

If the fan is severely damaged, you’ll need a new motor assembly, which is a more advanced repair. For most users, cleaning the fan will restore performance.

Step 6: Reset and Recalibrate

After cleaning, it’s a good idea to reset the S5’s firmware to ensure that the motor’s power settings are at their optimal values.

1. Plug the S5 back into the charger.
2. Wait for the indicator lights to confirm it’s fully docked.
3. Use the Roborock app to check for firmware updates. Install any available updates.
4. Perform a quick test run in a small area to confirm that suction feels correct.

Sometimes the app offers a “reset suction” or “calibrate suction” option that can fine‑tune the fan speed based on internal sensor feedback.

Step 7: Test and Fine‑Tune

With the robot reassembled, it’s time to test its performance.

• Choose a floor area that previously required multiple passes.
• Run the S5 on a higher suction setting.
• Observe the dust collection: The bin should fill quickly, and the floor should appear clean after a single pass.
• If suction still feels weak, re‑open the robot and double‑check for any missed debris in the filters or port.

Once you’re satisfied with the suction, re‑assemble the S5 and return it to its charging dock.

Maintenance Tips

Consistent performance comes from regular upkeep. Follow these simple habits to keep your S5 at peak suction.

• Empty the dustbin after each use to avoid clogging.
• Clean the HEPA filter monthly; replace it every six months or sooner if it becomes heavily clogged.
• Inspect the brushroll quarterly for tangles and replace if worn.
• Wipe the vacuum port once a month to prevent hair buildup.
• Run a quick vacuum cycle once a week even if no visible dirt is present; this helps maintain airflow.

By integrating these practices into your routine, you’ll reduce the need for major overhauls and keep your robot functioning efficiently for years.

Troubleshooting Quick FAQ

Conclusion

A drop in suction on your Roborock S5 doesn’t have to be a permanent inconvenience. By following the steps outlined above—cleaning the dustbin, inspecting and refreshing the brushroll, maintaining the filters, and ensuring the fan remains unobstructed—you can revive the vacuum’s performance quickly and cost‑effectively. Regular maintenance will keep the suction strong and extend the life of your robot, making it a reliable cleaning companion for years to come.
