Repairing Power Supply on Electrolux Pure One S12

Overview

The Electrolux Pure One S12 is a popular cordless stick vacuum known for its lightweight design and strong suction. Over time, its power supply—specifically the battery charger and internal power module—can fail, leaving the unit unable to charge or run. This guide walks you through diagnosing the problem, safely removing the old power supply, and installing a new one. Whether you prefer a DIY approach or simply want to understand the process, the steps below cover everything you need to get your vacuum back to life.

Safety Precautions

Before beginning any repair, keep these safety rules in mind:

• Unplug the vacuum and remove the battery pack completely.
• Work in a well‑ventilated area and avoid flammable materials nearby.
• If you are not comfortable with electrical components, consider hiring a professional.
• Use a non‑contact voltage tester to confirm no voltage is present on the power board before touching it.
• Keep all screws and small parts in a organized container to avoid loss.

Tools and Parts Needed

• Phillips head screwdriver (small size).
• Flathead screwdriver or plastic pry tool.
• Needle‑point tweezers.
• Replacement power supply module compatible with Electrolux Pure One S12 (often marked as “S12 Power Supply” or “Model 1234‑5678”).
• Anti‑static wrist strap (recommended).
• Small container or magnet for screws.

Make sure the new power supply matches the model number and voltage specifications of the original.

Diagnosing the Issue

1. Check the charger and cord.

   • Plug the charger into a known working outlet.
   • Inspect the cord for visible damage, kinks, or burn marks.
   • If the charger’s indicator light does not illuminate, try a different outlet or a known good charger.

2. Test the battery.

   • Remove the battery and measure its voltage with a multimeter.
   • A fully charged Li‑ion battery should read about 12 V.
   • If the battery voltage is low or dead, replace it before proceeding.

3. Inspect the power board.

   • Power down the vacuum and open the casing (instructions below).
   • Look for burnt components, swollen capacitors, or loose connections.

If all external checks appear fine but the vacuum still won’t charge or run, the internal power supply module is likely the culprit.

Opening the Vacuum

1. Remove the front cover.

   • The Pure One S12 uses a small Phillips screw near the base.
   • Unscrew it and gently pull the cover away.

2. Detach the battery connector.

   • Locate the metal clip that holds the battery’s power cable.
   • Slide the clip to the side and lift the cable out.

3. Remove the main power board.

   • The board is held by two or three small screws.
   • Carefully unscrew them and lift the board free.
   • Note the position of the board for reassembly.

4. Set the board aside.

   • Place it on a clean, non‑conductive surface.

Inspecting the Power Supply

• The power supply module is a small rectangular chip on the main board.
• It often has a small plastic housing with a solder pad.
• Look for discoloration, cracks, or a damaged heat sink.

If the module is visibly damaged or if you see any of the following signs, replace it:

• Discoloration or a burnt smell.
• Cracked heat sink or broken pins.
• Loose or missing solder connections.

Removing the Old Power Supply

1. Desolder the module.

   • Use a soldering iron with a fine tip.
   • Heat each solder pad for a few seconds, then lift the module with tweezers.
   • If the board uses a socket, you may simply pull the module out.

2. Clean the pads.

   • Use isopropyl alcohol and a brush to remove residue.
   • Ensure the pads are free of oxidation.

3. Remove any protective film on the new module.

Installing the New Power Supply

1. Place the new module onto the solder pads.

   • Align the pins carefully to avoid misplacement.

2. Solder the pins.

   • Heat each pad, apply solder, and let it cool.
   • Check for solid, shiny joints.

3. Reinforce with heat‑shrink tubing if recommended.

4. Double‑check the module orientation.

5. Reassemble the board.

   • Place the main board back onto its mounting points.
   • Secure it with the original screws.

6. Reconnect the battery.

   • Plug the battery cable back into the metal clip.

7. Replace the front cover and tighten the screw.

Testing the Vacuum

1. Plug the charger into a known good outlet.
2. Observe the charging indicator.
   • It should light up, indicating the new power supply is functioning.
3. Run the vacuum.
   • Turn it on and verify that it powers up and operates at expected suction levels.

If the vacuum still does not power on, double‑check all solder connections and ensure the new module is the correct part number.

Troubleshooting Common Problems

• Charger indicator stays off

  • Verify the charger cable and outlet.
  • Check the power supply module’s output pin with a multimeter.

• Vacuum powers on but runs poorly

  • Inspect the motor and fan for obstructions.
  • Clean or replace the filter.

• Battery does not hold charge

  • Replace the battery if it is older than two years.
  • Test with a known good battery.

• Solder joints appear loose

  • Reheat and reapply solder.
  • Use a small amount of flux for better adhesion.

Maintenance Tips to Extend Power Supply Life

• Avoid exposing the vacuum to moisture.
• Clean the charging port regularly to prevent dust buildup.
• Store the vacuum on a flat surface when not in use.
• Keep the firmware up to date (if your model supports firmware updates).

Final Thoughts

Repairing the power supply on an Electrolux Pure One S12 is a straightforward process when approached methodically. By following the safety precautions, gathering the right tools, and carefully desoldering and replacing the module, you can restore your vacuum’s performance without spending on a new unit. Remember to keep all parts organized during the process, and double‑check your work before reassembling. With a little patience and precision, your vacuum will be back to cleaning your floors in no time.
