LG T4900 Dryer Error Code 12 Quick Troubleshooting Guide

LG T4900 Dryer Error Code 12 Quick Troubleshooting Guide

When your LG T4900 dryer flashes the red “12” error code, the appliance stops and you’re left with damp laundry and a nagging sense of frustration. This guide will walk you through every step you can take at home to identify, diagnose, and often fix the issue before you have to call a technician. The information below is presented as a clear, step‑by‑step tutorial so you can quickly restore your dryer’s performance.

Understanding What Error Code 12 Means

Error code 12 on LG dryers indicates that the unit has detected a problem with the heating element or its temperature sensor. The dryer is designed to prevent damage and fire hazards, so it halts operation when it senses that the temperature is too high, too low, or that the element is not functioning. The exact cause can vary from a faulty thermostat to a clogged vent.

Common Causes of Error Code 12

Before you dive into the technical details, it’s helpful to know the most frequent reasons for this error:

• Malfunctioning Heating Element – Over time the element may develop a fault, making it impossible to reach the desired temperature.
• Temperature Sensor Failure – The sensor may not be reading accurately, causing the control board to think the dryer is overheating or underheating.
• Vent Blockage or Restricted Airflow – Dust or lint buildup can restrict airflow, making the dryer work harder and raising internal temperatures.
• Electrical Connection Issues – Loose wires or corroded terminals can disrupt power delivery to the heating circuit.
• Control Board Fault – The microcontroller may misinterpret signals, triggering an error unnecessarily.

Preparing Your Work Area

1. Unplug the Dryer
   Safety first – make sure the appliance is disconnected from the power outlet. Keep the cord away from any heat source.

2. Clear the Surroundings
   Remove any items from the top and front of the dryer, allowing easy access to the control panel, vent, and door hinge.

3. Gather Basic Tools
   You’ll need a Phillips screwdriver, a multimeter (set to DC volts or ohms), a lint brush, and a vacuum or compressed‑air can. Optionally, a flashlight will help you inspect hidden areas.

Step‑by‑Step Troubleshooting

1. Inspect the Vent System

• Locate the vent hose that connects the dryer to the outside vent hood.
• Remove the hose from the back of the dryer and pull it out.
• Check for lint, debris, or a kink that might block airflow.
• If you find a blockage, clean the hose thoroughly with a brush or vacuum.
• Re‑install the hose, ensuring a tight fit and no snags.
• Inspect the vent hood outside; if it’s clogged, clear it as well.

If the vent was clogged, this can reduce airflow and cause the dryer to overheat, triggering error code 12.

2. Check the Heating Element

• Remove the front panel or side door cover to expose the heating element (usually a copper coil).
• Visually inspect for obvious damage such as breaks, burns, or discoloration.
• Use the multimeter to test continuity: set to ohms, touch the probes to the two ends of the coil.
  • A normal reading is typically between 5 and 25 ohms, depending on the model.
  • If the meter reads “infinite” or a very high value, the element is open and needs replacement.
• If the element reads within normal limits, move to the next step.

3. Test the Temperature Sensor (Thermostat)

• The thermostat is located near the heating element or at the front of the dryer.
• Using the multimeter set to ohms, touch the probes to the sensor’s terminals.
  • A healthy sensor will show a resistance that changes with temperature.
  • If you get zero or infinite resistance, the sensor is faulty.
• If the sensor is defective, replace it with a model‑specific part.

4. Examine Wiring and Connections

• Inspect all visible wires between the heating element, thermostat, and control board.
• Look for frayed insulation, burn marks, or loose connectors.
• Firmly tighten any loose terminals.
• If you see corrosion, clean the contacts with a contact cleaner or isopropyl alcohol, then dry and reconnect.

5. Reset the Dryer

Once you have addressed any physical problems, reset the dryer:

• Re‑install the front panel or door cover.
• Plug the dryer back into the outlet.
• Turn on the unit and observe the display for a few minutes.
• If the “12” error disappears and the dryer runs normally, the issue is resolved.
• If the code reappears, proceed to the next step.

6. Test the Control Board

• The control board is the brain of the dryer.
• A failure in the board’s temperature monitoring circuitry can falsely trigger error code 12.
• Inspect for any scorch marks or swollen capacitors.
• If you suspect a board problem, the safest approach is to replace the board with a new OEM unit.

How to Replace Key Components

Replacing the Heating Element

1. Disconnect Power – Already unplugged.
2. Remove the Old Element – Unplug the terminal connectors and gently lift the coil out.
3. Insert the New Element – Position the new coil where the old one was, connecting the terminals securely.
4. Re‑test – Follow the heating element testing procedure to ensure continuity.

Replacing the Temperature Sensor

1. Locate the Sensor – Usually a small cylinder with two wires.
2. Detach Wires – Unscrew or unplug the connectors.
3. Install New Sensor – Connect the new sensor’s wires to the same terminals.
4. Confirm Functionality – Use the multimeter test again.

Replacing the Control Board

1. Mark Wire Positions – Take a photo or note where each wire plugs in.
2. Unplug All Wires – Carefully remove every wire from the board.
3. Remove the Old Board – Unscrew the mounting screws.
4. Install New Board – Secure the board with screws, then reconnect all wires exactly as before.
5. Power On – Test to confirm the error code is cleared.

When to Call a Professional

• Electrical Work Beyond Your Comfort – If you encounter major wiring issues or suspect a problem with the dryer’s main power supply.
• Persistent Error After All Checks – If error code 12 returns even after replacing all components, a technician may need to diagnose hidden faults.
• Complex Control Board Repair – While a board replacement can be done at home, precise calibration may require professional tools.

Preventative Maintenance Tips

1. Clean the Lint Filter Daily – A clogged filter forces the dryer to work harder, raising temperatures.
2. Vacuum the Vent Hoses Monthly – Remove lint from the interior of the hose and the external vent.
3. Inspect the Door Seal – A weak seal can cause heat loss and increased load.
4. Run a Dry Cycle with Empty Drum – This helps identify any overheating or sensor issues before you use the dryer normally.
5. Schedule Annual Professional Service – A technician can inspect and clean internal components that you can’t reach.

FAQ

What does a red “12” on the display mean?
It indicates a heating element or temperature sensor problem that triggers an overheat protection shutdown.

Can I ignore the error code and keep drying clothes?
No. Continuing to operate the dryer in this state risks damage to the unit and potential fire hazards.

Is the heating element replacement expensive?
Prices vary, but a typical LG heating element can cost between $30 and $50. Labor for a professional installation is extra unless you do it yourself.

Why did the error appear after a power outage?
Power surges can damage the control board or disconnect internal sensors, leading to error code 12.

Can a vent blockage cause a 12 error?
Yes. Restricted airflow forces the dryer to overheat, which the control board detects and flags with the error code.

Quick Recap

• Step 1: Unplug dryer and clear the area.
• Step 2: Clean the vent system and check for airflow restrictions.
• Step 3: Test the heating element for continuity.
• Step 4: Inspect the temperature sensor for proper resistance.
• Step 5: Verify all wiring connections are secure.
• Step 6: Reset the dryer and observe the display.
• Step 7: If the error persists, examine or replace the control board.

If you follow these steps carefully, you will either resolve the issue yourself or have a clear understanding of what to explain to a technician, saving time and money.

By staying patient, methodical, and thorough, you can bring your LG T4900 dryer back to reliable operation without a costly service call. Remember that regular maintenance and quick attention to warning lights are the best defense against future errors.
